Descripción
The regulated working pressure can be precisely adjusted with the pressure reducer and is indicated with the pressure gauge. The quick coupling allows various pneumatic devices to be quickly commissioned without the need for tools. The 24 liter tank offers sufficient air reserves. Oil lubrication of the pump ensures long compressor life. The check valve and safety valve ensure operator safety at all times. The robust boiler has a 10-year warranty against corrosion.
CHARACTERISTICS
- Oil lubrication ensures durability
- The 24 l tank offers sufficient air reserves
- Numerous applications up to 8 bar adjustable thanks to a pressure reducer
- Pressure gauge and quick coupling for regulated operating pressure
- Rubber wheels and carrying handle for easy transport
- Base with rubber cushion to reduce noise
- 10 year warranty against boiler corrosion
- Check valve, safety valve
- A drain screw allows for easy maintenance
SPECIFICATIONS
- Red supply: 220-240 V 50 Hz
- Max power Motor power (S2 time S2): 1500 W 2 PS 15 min
- Engine speed: 2850 min^-1
- Pump speed: 2850 min^-1
- Suction capacity: 165 L/min
- Output power at 0 bar: 110 L/min
- Output power at 4 bar: 75 L/min
- Output power at 7 bar: 55 L/min
- Max pressure operating: 8 bar
- Tank capacity: 24 L
- Number of cylinders: 1 Pieces
- sound pressure level; Lpa: 73.4 dB(A)
